G3046QOU 3000 Circuit Breaker Housing Fitting in Gray
Circuit breaker housing for Square D Type QOU breakers in 3000 Series Raceways, rated up to 50A maximum capacity
The Wiremold G3046QOU is a specialized fitting designed to integrate electrical protection directly into a Wiremold 3000 Series Raceway system. This gray housing allows installers to mount Square D Type QOU one-, two-, or three-pole breakers within the raceway. The fitting supports a maximum capacity of up to 50A, providing a streamlined way to manage power distribution in commercial environments. Because this is part of the 3000 Series Steel Raceway family, it is designed to maintain the integrity and appearance of the metal raceway system while providing necessary circuit protection.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Color | Gray |
| TAA Compliant | Yes |
| Certifications | TAA |
| Warranty | 1-Year from Installation or 2-Years from Day of Sale |
Resources
Questions about this part
Which breakers fit in the G3046QOU housing?
This fitting is designed specifically for Square D Type QOU one-, two-, or three-pole breakers.
What is the maximum amperage for this breaker housing?
The G3046QOU is rated for a maximum capacity of up to 50A.
Is the G3046QOU TAA compliant?
Yes, this product is TAA compliant.
What raceway system is this fitting for?
This is a 3000 Series Raceway fitting.
What is the warranty for this Wiremold fitting?
It carries a 1-year warranty from installation or a 2-year warranty from the day of sale.
