G20GBA512 Steel Plugmold® Multioutlet System in Gray
5 ft Steel Plugmold Multioutlet System in gray with 12 in receptacle spacing for dry location installations
The Wiremold G20GBA512 is a 5 ft (1.5 m) Steel Plugmold® Multioutlet System designed for providing reliable power in electrically busy dry locations. This steel raceway is constructed with a gray baked enamel finish that can be painted to match specific site requirements, or left as is to complement the existing décor. This specific model features a 12 in (30.5 cm) receptacle spacing, allowing for five single outlets within the 5 ft run. The construction provides superior strength for any installation in a dry environment. Because this system is part of the GBA series, it is compatible with a full range of fittings, including single- and dual-gang boxes. This allows installers to wire devices directly into the raceway or incorporate surge or GFCI protection to protect the Plugmold® strip. This product is TAA Compliant and meets RoHS material restrictions.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Length | 5 ft (1.5 m) |
| Receptacle Spacing | 12 in (30.5 cm) |
| Color | Gray |
| TAA Compliant | Yes |
| Certifications | TAA |
| Warranty | 1-Year from Installation or 2-Years from Day of Sale |
Resources
Questions about this part
Can I use this Plugmold system in wet locations?
No, this steel raceway is designed for use in any dry location installation.
What is the receptacle spacing for the G20GBA512?
This 5 ft model features a center-to-center receptacle spacing of 12 in (30.5 cm).
Can this raceway be painted to match the room?
Yes, the gray baked enamel finish on this unit can be painted to suit your application.
What other options are available in this series?
The GBA series includes different lengths, such as 6 ft, and an Ivory ScuffCoat finish instead of gray.
Is this product TAA compliant?
Yes, this model is TAA Compliant and meets RoHS material restrictions.
