Forum™ Lectern 6RU Under Worksurface Rack in Graphite Powdercoat
6RU undermount rack for Forum Lecterns, featuring a locking vented door and Graphite powdercoat finish
The Forum™ FMR-6UT6G-FD provides 6RU of secure, undermount rack space specifically designed for installation below the worksurface of a Forum Lectern. This steel rack is TAA compliant and features a Graphite powdercoat finish. For ease of installation, the rack utilizes pre-installed screws in the bottom of the worksurface. It is designed to be installed in the center when used with a 42" wide Forum Lectern, while 60" and 72" Forum Lectern models allow for left or right justification. Note that installing this undermount rack will void ADA compliance for the 42" and 60" Forum Lectern models. The included forward rackrail is adjustable in depth to accommodate your specific equipment requirements. This unit is forward compatible and utilizes a vented front door with a locking mechanism to ensure secure storage of AV equipment. The vented base is designed to facilitate the mounting of small devices using Forward accessories, such as blank panels, vent panels, or lacer bars.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Depth | 18.7 in (47.5 cm) |
| Height | 10.9 in (27.7 cm) |
| Product Weight | 22 lbs (10 kg) |
| Rack Units | 6 RU |
| Shipping Weight | 24 lbs (10.9 kg) |
| Weight Capacity | 40 lbs (18.1 kg) |
| Width | 22.25 in (56.5 cm) |
| Base Series | Forum |
All other specifications 9
| Color | Graphite |
| Federal Ops Country of Origin | US |
| Forward Compatible | Yes |
| Manufacturer | Middle Atlantic Products |
| Material | Steel |
| Rack Rail Type | Forward Rackrail |
| TAA Compliant | Yes |
| UPC | 656747404795 |
| Certifications | Prop 65REACHRoHSTAATASCA |
Resources
Questions about this part
Where can I mount the FMR-6UT6G-FD on a Forum Lectern?
On a 42" wide Forum Lectern, this 6RU rack installs in the center. For 60" and 72" models, it can be installed either left or right justified.
What is the weight capacity of this 6RU undermount rack?
The FMR-6UT6G-FD has a weight capacity of 40 lbs (18.1 kg) and weighs 22 lbs (10 kg) itself.
Will installing this rack affect ADA compliance?
Yes, installing the Forum™ Undermount Rack will void ADA compliance on both 42" and 60" Forum Lectern models.
What accessories are compatible with the FMR-6UT6G-FD?
This rack is forward compatible and works with tool-free accessories like vent panels, blank panels, and lacer bars.
Which document should I use for installation instructions?
For specific installation guidance, refer to the Forum™ Collaboration Suite Lectern Undermount Rack Option Instruction Sheet (PDF).
