EHWB8-BK Evolution™ Eight Gang Hinged Wall Box in Black
Eight gang hinged wall box in black, designed for 16" on center stud spacing with 3 5/8" depth
The Wiremold EHWB8-BK is an eight-gang hinged wall box designed to house power, communications, and A/V devices in upscale environments. It is engineered to fit into 16" on center openings between studs in standard 2"x 4" walls and supports both new work and old work applications. This box features two 4-gang standard NEMA size openings and includes a built-in tunnel that allows wiring compartments on both sides of the box to be fed with a single conduit. This design enables multiple service points to be daisy-chained together via a cable pass-through capability, which can reduce the total number of conduit runs required. For security and maintenance, the cover opens a full 180° and features an integrated handle, a lock and key set, and a flush egress door for cabling. This SKU is the black version of the Evolution Series hinged box; the finished cover assembly, EHWBC, is sold separately.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Color | Black |
| TAA Compliant | Yes |
| Certifications | TAA |
| Warranty | 1-Year from Installation or 2-Years from Day of Sale |
Resources
Questions about this part
The EHWB8-BK ships with a temporary cover, but you will need to purchase the finished cover assembly (EHWBC) separately to complete the installation.
The EHWB8-BK ships with a temporary cover, but you will need to purchase the finished cover assembly (EHWBC) separately to complete the installation.
Will this wall box fit my existing devices?
Yes, this box is designed to accept standard 1- to 4-gang device plates, including Legrand AVIP devices and A/V devices from other leading manufacturers.
How much space is available behind the device plates?
The box provides 3 5/8" [92mm] of space behind the device plates, which accommodates the extra depth often required for wiring larger A/V devices.
What type of conduit can be used with this box?
This box accepts trade size service feeds from 3/4" up to 2". The knockout plates are removable and interchangeable to provide multiple feed options.
Is the EHWB8-BK suitable for TAA requirements?
Yes, the EHWB8-BK is TAA compliant and is UL Listed to U.S. and Canadian safety standards.
