dash™ 4-Cube FPC in Graphite
Furniture Power Center in Graphite featuring 4 outlets and combo USB A/C ports for in-surface power applications
The Wiremold F4RRUS6NRGC is a dash™ 4-Cube FPC designed for in-surface power integration within furniture or desktop environments. This unit features a specific configuration of components arranged from left to right, including two 15A tamper-resistant outlets, one combo 15W USB A/C port, and a mechanical switch. The assembly includes a 6 ft (1.83 m) right-exit power cord for connecting to a power source, along with a secondary 10" (254 mm) cord that features a switch-controlled receptacle on the end. This Graphite finish is one of several options available, as additional trim plate finishes can be acquired separately in stainless, bronze, or brass. This component is part of the dashFPC series, and installers can use the dash™ Configurator to determine alternative cube combinations for different furniture or desktop power center requirements.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Color | Graphite |
| Federal Ops Country of Origin | China |
| Outlet Count | 4 |
| USB Port | Yes |
| Certifications | UL 962A |
| Warranty | 1-Year from Installation or 2-Years from Day of Sale |
| Cord Length | 6 ft |
Resources
Questions about this part
What is the configuration of the outlets on the F4RRUS6NRGC?
This unit contains two 15A tamper-resistant outlets, one 15W USB A/C combo port, and a mechanical switch.
Can I get this in a different finish?
Yes, while this SKU is Graphite, additional trim plate finishes are available separately in stainless, bronze, and brass.
What is the cord length for this power center?
The main power cord is 6 ft (1.83 m) with a right-exit, and it includes an additional 10" (254 mm) cord with a switch-controlled receptacle.
How can I customize the cube layout?
You can use the online dash™ Configurator to explore various cube combinations for both furniture and desktop power centers.
What certifications does this product hold?
The F4RRUS6NRGC is UL 962A certified and carries the CETLUS mark.
