Da-Lite Radio Frequency Single Channel Wall Switch For Wireline (220V)
Wireless radio frequency wall switch for 220V Wireline Advantage electric screens
The Da-Lite 29470 is a radio frequency (RF) single channel wall switch designed to function as a wireless radio transmitter for electric screens. This specific SKU is configured for use with the 220V Wireline Advantage series. Unlike the 28359 model, which is compatible with 120V Wireline Advantage and both 120V and 220V Studio or Arena electric screens, the 29470 is intended exclusively for 220V Wireline applications. It acts as a low voltage trigger to control screen movement via RF signal, eliminating the need for hardwired control lines to the motor.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Shipping Weight | 0.5 lbs (0.2 kg) |
| Accessory Type | ControlsLow Voltage Trigger |
| Product Selection | For Wireline (220V) |
| Screen Type | Electric |
Resources
Questions about this part
Will the 29470 work with my 120V Wireline Advantage screen?
No, this 29470 SKU is specifically for 220V Wireline Advantage screens; the 28359 model is required for 120V Wireline Advantage applications.
What is the difference between the 29470 and the 28359 wall switch?
The 29470 is compatible with 220V Wireline Advantage, while the 28359 is compatible with 120V Wireline Advantage and 120V/220V Studio or Arena electric screens.
Is this a hardwired switch or a wireless transmitter?
This is a wireless radio frequency (RF) transmitter that provides low voltage trigger control for compatible RF screen motors.
Which Da-Lite screens are compatible with this switch?
The 29470 is designed for use with 220V Wireline Advantage electric screens.
Where can I find installation and connection details for the 29470?
Installation and connection information can be found in the 29470 Instructions (PDF) document.
