Da-Lite Model C, 144" x 144" with Matte White - 40284
Manual square projection screen measuring 144" x 144" with a Matte White non-tensioned surface
The Da-Lite 40284 is a manual projection screen designed for large rooms that require flexible ceiling or wall mounting. This 144" x 144" square format screen features a Matte White non-tensioned surface optimized for standard resolution front projection applications. For smooth and reliable operation, the Model C utilizes heavy-duty spring assemblies combined with nylon bushings and permanently lubricated steel ball bearings. This specific SKU does not include the Controlled Screen Return (CSR) feature found on other Model C versions. For installations requiring specific alignment, optional floating mount brackets can be positioned to the left or right of the wall or ceiling studs. This TAA compliant unit is manufactured in the US and includes a pull cord for manual operation.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Screen Diagonal | 204 in (518.2 cm) |
| Screen Height | 144 in (365.8 cm) |
| Shipping Weight | 85 lbs (38.6 kg) |
| Size | 144" x 144" |
| Application | CeilingWall |
| Federal Ops Country of Origin | US |
| Projection Type | Front Projection |
| Screen Format | Square |
| Screen Surface Features | Standard Resolution |
| Screen Type | Manual |
| Surface | Matte White (non-tensioned) |
| Certifications | TAA |
Resources
You'll need these with it
Da-Lite Ceiling Trim Kit - 96384
96384$332.80
Da-Lite Pull Rod - 74689
74689$14.40
Da-Lite Floating Mounting Bracket White
77027$106.40
Da-Lite Floating Mounting Bracket Black
77028$106.40
Da-Lite Mounting and Extension Brackets White No. 23 Brackets
40933$56.00
Da-Lite Mounting and Extension Brackets White No. 6 Brackets
40932$21.60
Da-Lite Mounting and Extension Brackets White No. 11 Brackets
40957$44.80
Da-Lite Mounting and Extension Brackets Black No. 6 Brackets
98035$21.60
Da-Lite Mounting and Extension Brackets Black No. 11 Brackets
98036$44.80
Da-Lite Mounting and Extension Brackets Black No. 23 Brackets
98037$56.00
Questions about this part
Is the Da-Lite 40284 TAA compliant?
Yes, this Model C screen is TAA compliant and manufactured in the USA.
Can I mount the Model C 40284 on a wall or ceiling?
The 40284 is designed for both wall and ceiling applications. You can also use Da-Lite Floating Mounting Brackets (SKUs 77027 or 77028) to align the screen with your specific stud layout.
Does this screen include a return mechanism?
This SKU features a standard heavy-duty spring assembly. It does not include the Controlled Screen Return (CSR) feature available on other Model C variants.
What mounting accessories are compatible with the 40284?
Compatible accessories include the Da-Lite Ceiling Trim Kit (96384), Da-Lite Pull Rod (74689), and various Da-Lite Mounting and Extension Brackets (such as SKUs 40932, 40933, 40957, 98035, 98036, 98037, or 77027/77028).
What is the surface type for this Model C screen?
The 40284 uses a Matte White non-tensioned surface intended for standard resolution front projection.
