Da-Lite Fast-Fold Deluxe Screen System, 86.5 x 138.5 in Da-Tex - 38311KHD
Portable rear projection screen with 163" diagonal size, 86.5" x 138.5" dimensions, and Da-Tex surface for wide format applications
The Da-Lite 38311KHD is a portable Fast-Fold Deluxe Screen System designed for demanding rental and staging environments. This 163" diagonal (414 cm) system features a wide 16:10 screen format with dimensions of 86.5" x 138.5" (219.7 x 453.4 mm). It utilizes a Da-Tex surface specifically optimized for rear projection applications. The frame and legs are constructed from 1 1/4” aluminum tubing and include an intuitive leg-to-frame locking mechanism that prevents lost parts during rapid setup and tear-down. This model is equipped with a black frame and heavy-duty legs for increased stability. To ensure longevity and ease of use, the system includes an adjustable corner brace to correct frame bowing over time and features RF welded binding for a clean, professional aesthetic. This TAA compliant system is an ideal solution for high-resolution AV experiences in portable configurations. It is manufactured in the US.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Screen Diagonal | 163 in (414 cm) |
| Screen Height | 86.5 in (219.7 cm) |
| Shipping Dimensions | 44" x 18" x 13" (111.8 x 45.7 x 33 cm) |
| Shipping Weight | 105 lbs (47.6 kg) |
| Size | 86.5" x 138.5" or 163" diagonal |
| Application | Portable |
| Federal Ops Country of Origin | US |
| Projection Type | Rear Projection |
All other specifications 8
| Screen Format | Wide (16:10) |
| Screen Options | Black Frame and Heavy-Duty Legs |
| Screen Surface Features | Standard Resolution |
| Screen Type | Portable |
| Surface | Da-Tex |
| TAA Compliant | Yes |
| UPC | 717068745988 |
| Certifications | TAA |
Resources
You'll need these with it
Da-Lite Fast-Fold Deluxe Repair Kit - 36975
36975$620.80
Da-Lite Fast-Fold Deluxe Repair Kit - 89875
89875$620.80
Da-Lite Fill Strips
41298$152.00
Da-Lite Leg Saver Back Brace
89581
Da-Lite Hinged Screen Joining Clamp
89518$132.80
Da-Lite Skirt Adapter Brackets
90751
Da-Lite Fast-Fold Deluxe Drapery Presentation Kits, 86.5" x 138.5" - 39908GRP
39908GRP$3,155.20
Da-Lite Fast-Fold Deluxe Drapery Presentation Kits, 86.5" x 138.5" - 39908P
39908P$3,155.20
Da-Lite Fill Strip Clamp
90748$28.80
Da-Lite Straight Screen Joining Clamp
90749$46.40
Da-Lite Fast-Fold Skirt, 86.5" x 138.5" Black Skirt
39932$883.20
Da-Lite Fast-Fold Skirt, 86.5" x 138.5" Gray Skirt
39932GR$883.20
Questions about this part
Will this Da-Lite 38311KHD screen fit my rear projection setup?
Yes, this is a rear projection screen utilizing a Da-Tex surface with a 16:10 wide format, specifically designed for high-resolution rear projection applications.
What is included with the Fast-Fold Deluxe Screen System?
This system includes the 86.5" x 138.5" screen, the heavy-duty legs, and a wheeled carrying case to facilitate easy transport between job sites.
What should I buy to extend the life of this screen?
To maintain the system, you can utilize Da-Lite accessories like the 38327 replacement surface or the 89581 Leg Saver Back Brace to ensure structural integrity.
How does this model differ from older Fast-Fold systems?
The 38311KHD features an intuitive leg-to-frame locking mechanism designed to prevent parts from being lost, which is distinct from the older Speedy Crank design.
Where can I find the technical submittals for this screen?
Technical documentation is available via the Fast-Fold Deluxe Specification Sheet or the detailed Fast-Fold Deluxe CSI 3-Part Specifications.
