Da-Lite Cosmopolitan Series, 70" x 70" with High Contrast Matte White - 92566S
Square electric projection screen, 70" x 70" format, High Contrast Matte White surface with a silent 120V motor
The Da-Lite 92566S is a Cosmopolitan Series electric screen featuring a square 70" x 70" format. Designed for large venue applications, this projection screen is suitable for both ceiling and wall mounting. The unit utilizes a High Contrast Matte White non-tensioned surface to optimize front projection performance. This specific model is equipped with a silent 120V (60Hz) motor to minimize noise during operation. The assembly features a black backing to help retain projected brightness on the front surface. This TAA compliant screen is constructed with a single-piece steel case that includes integrated mounting holes in the end caps. For installers, the Cosmopolitan Series provides a seamless surface and comes with a standard white powder-coated housing finish. It is a versatile solution for professional environments requiring a square aspect ratio.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Overall Dimensions | 92" x 8" x 6" (2336.8 x 203.2 x 152.4 mm) |
| Screen Diagonal | 99 in (251.5 cm) |
| Screen Height | 70 in (177.8 cm) |
| Screen Width | 70 in (177.8 cm) |
| Shipping Weight | 42 lbs (19.1 kg) |
| Size | 70" x 70" |
| Application | CeilingWall |
| Federal Ops Country of Origin | US |
All other specifications 8
| Motor | Silent 120V (60Hz) |
| Projection Type | Front Projection |
| Screen Format | Square |
| Screen Surface Features | Standard Resolution |
| Screen Type | Electric |
| Special Features | Large Venue |
| Surface | High Contrast Matte White (non-tensioned) |
| Certifications | TAA |
Resources
You'll need these with it
Da-Lite Floating Mounting Bracket White
77027$106.40
Da-Lite Ceiling Trim Kit - 96382
96382$280.80
Da-Lite Floating Mounting Bracket Black
77028$106.40
Da-Lite Locking Switch Cover Plate
98837$102.40
Da-Lite Single Motor Low Voltage Control System 120 Volt
40973$316.00
Da-Lite Replacement Wall Switch Stainless Steel
92055$95.20
Da-Lite Replacement Wall Switch White (standard)
80575$71.20
Key Operated 110 Volt Switch
74490$116.00
Questions about this part
Will this Da-Lite 92566S screen fit my setup?
This is a square 70" x 70" screen designed for front projection. The 99 in (251.5 cm) diagonal format is ideal for environments requiring a 1:1 aspect ratio.
What mounting options are available for the 92566S?
The Cosmopolitan Series can be installed via ceiling or wall mount. You may require a Da-Lite 96382 Ceiling Trim Kit or a Da-Lite 77027/77028 Floating Mounting Bracket for specific finishes.
What kind of control is used for the motor?
This model features a silent 120V (60Hz) motor. It is compatible with a Decora-style, three-position wall switch, such as the Da-Lite 80575 or 92055 replacement switches.
Is the 92566S TAA compliant?
Yes, this product is TAA compliant, making it suitable for projects with specific federal acquisition requirements.
Which documents are available for submittals?
Full technical details can be found in the Cosmopolitan Series Specification Sheet, and CAD/BIM models are available for architectural integration.
