Da-Lite Advantage Series, 216" x 216" with Matte White - 36867EB
Ceiling recessed square projection screen, 216" x 216" dimensions, featuring a matte white surface and automatic closure door
The Da-Lite 36867EB is a ceiling recessed electric projection screen designed for large venue environments. This specific SKU is a Case/Box Only for Rough-In, meaning the screen housing is intended to be installed during the rough-in construction stage, while the screen surface assembly is added during the finishing stage. This two-stage process allows for a clean, integrated appearance. This model features a square 216" x 216" screen format with a 305 in (774.7 cm) diagonal, utilizing a matte white non-tensioned surface for front projection applications. The unit includes an automatic closure door and a standard black drop to maintain high brightness levels on the projection surface. For international installations, this unit is equipped with a 220V (50Hz) motor. The UL plenum rated case features a white powder-coated finish for a professional aesthetic. This series is compatible with standard low voltage control (LVC) and offers flexible operation via a Decora-style, three-button wall switch.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Screen Diagonal | 305 in (774.7 cm) |
| Screen Height | 216 in (548.6 cm) |
| Size | 216" x 216" |
| Application | Ceiling Recessed |
| Built-In Control | Standard Low Voltage Control |
| Closure Door | Automatic Closure Door |
| Drop Type | Standard Black Drop |
| Motor | 220V (50Hz) for Export |
All other specifications 7
| Product Selection | Case/Box Only for Rough-In |
| Projection Type | Front Projection |
| Screen Format | Square |
| Screen Surface Features | Standard Resolution |
| Screen Type | Electric |
| Special Features | Large Venue |
| Surface | Matte White (non-tensioned) |
Resources
You'll need these with it
Questions about this part
Is this the complete screen or just the housing?
This specific SKU (36867EB) is the Case/Box Only for Rough-In, designed to be installed during the construction phase.
What voltage is the motor for this model?
This model is equipped with a 220V (50Hz) motor intended for export use.
Can I control this screen with a wall switch?
Yes, it features standard low voltage control (LVC) and is compatible with Decora-style, three-button wall switches.
Does the screen include a protective cover?
Yes, this model includes an automatic closure door to protect the screen surface when not in use.
What is the required installation application for this SKU?
The 36867EB is designed specifically for ceiling recessed applications.
