Da-Lite Advantage Series, 108" x 108" with Matte White - 88103E
Ceiling recessed square electric screen, 108" x 108" Matte White surface, featuring an automatic closure door
The Da-Lite 88103E is a ceiling recessed electric screen designed for large venue applications. This 108" x 108" square format screen features a Matte White non-tensioned surface, which is ideal for front projection. It utilizes a standard black drop with an automatic closure door to protect the screen surface when not in use. The unit is built with a white powder-coated case and is UL plenum rated. This specific model is designed for international use, featuring a 220V (50Hz) motor. It is TAA compliant and includes standard low voltage control for flexible operation. For installers, the Advantage Series offers a two-stage installation process, allowing the housing to be installed during rough-in construction while the surface assembly is completed during the finishing stage. The sliding installation brackets provide significant mounting flexibility for attachment to structures above a drop ceiling.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Screen Diagonal | 153 in (388.6 cm) |
| Screen Height | 108 in (274.3 cm) |
| Shipping Weight | 149 lbs (67.6 kg) |
| Size | 108" x 108" |
| Application | Ceiling Recessed |
| Built-In Control | Standard Low Voltage Control |
| Closure Door | Automatic Closure Door |
| Drop Type | Standard Black Drop |
All other specifications 11
| Federal Ops Country of Origin | US |
| Motor | 220V (50Hz) for Export |
| Product Selection | Complete Screen |
| Projection Type | Front Projection |
| Screen Format | Square |
| Screen Surface Features | Standard Resolution |
| Screen Type | Electric |
| Special Features | Large Venue |
| Surface | Matte White (non-tensioned) |
| TAA Compliant | Yes |
| Certifications | TAA |
Resources
You'll need these with it
Questions about this part
What is the purpose of the automatic closure door on the 88103E?
The automatic closure door protects the Matte White screen surface by covering it when the unit is not in use.
Does this screen include control options?
The 88103E features standard low voltage control. You can also add a Da-Lite 40975 Low Voltage Wall Switch for manual operation.
Is the 88103E suitable for ceiling recessed installations?
Yes, this is a ceiling recessed model that includes a white powder-coated, UL plenum rated case.
What motor voltage is required for this model?
This SKU is equipped with a 220V (50Hz) motor specifically for export use.
Is this screen TAA compliant?
Yes, this product is TAA compliant.
