Da-Lite Advantage Manual With CSR, 60" x 60" with High Contrast Matte White - 92692B
Square ceiling recessed manual projection screen with High Contrast Matte White surface and CSR controlled return
The Da-Lite 92692B is a manual projection screen designed for ceiling recessed applications. Featuring a 60" x 60" square screen format and an 85 in (215.9 cm) diagonal, this unit utilizes a High Contrast Matte White non-tensioned surface. A key feature of the Advantage series is the integrated ceiling trim, which is designed to conceal the rough opening once installed, eliminating the need for additional finishing work by the installer. This specific SKU includes the Controlled Screen Return (CSR) mechanism, which ensures a quiet and controlled movement when the screen returns to the case; please note that the screen must be fully extended during use. The white powder-coated housing includes a black backing to help retain projected brightness. For construction efficiency, the installation is a two-stage process: the screen case can be mounted during the rough-in phase, while the fabric assembly is completed during the final finishing stage. This TAA compliant product is manufactured in the US.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Screen Diagonal | 85 in (215.9 cm) |
| Screen Height | 60 in (152.4 cm) |
| Shipping Weight | 35 lbs (15.9 kg) |
| Size | 60" x 60" |
| Application | Ceiling Recessed |
| Federal Ops Country of Origin | US |
| Product Selection | Case/Box Only for Rough-In |
| Projection Type | Front Projection |
All other specifications 5
| Screen Format | Square |
| Screen Surface Features | Standard Resolution |
| Screen Type | Manual |
| Surface | High Contrast Matte White (non-tensioned) |
| Certifications | TAA |
Resources
You'll need these with it
Questions about this part
Will the Da-Lite 92692B fit my ceiling installation?
This is a ceiling recessed model designed to be installed during the rough-in or finishing stages. The integrated trim is intended to cover the rough opening once the screen is in place.
How does the CSR mechanism work on this screen?
The Controlled Screen Return (CSR) feature provides a quiet and controlled return to the case. Note that for proper operation, the screen must be fully extended during use.
What is required for the rough-in stage of installation?
The screen case can be installed during the rough-in construction stage, allowing the fabric assembly to be completed later during the finishing stage.
Does this screen require additional trim work?
No, the Advantage line is designed with ceiling trim already in place to conceal the rough opening, which eliminates the need for additional trim work after installation.
Which document should I use for submittals?
For technical details, you can refer to the Advantage Manual Specification Sheet or the Advantage Manual With CSR Product Information Sheet available in the resources tab.
