861QTCAB Wood Floor Box Assembly in Brass
Brass wood floor box assembly with prewired 15A quad receptacle for tile, wood, or carpet applications
The Wiremold 861QTCAB is a brass wood floor box assembly designed for installations in tile, wood, or carpet floors. This unit comes prewired with a 15A quad receptacle and can be configured as either a standard or isolated ground setup. The die-cast aluminum construction features three 1/2'' trade size knockouts, located with two on the sides and one on the bottom, providing 18 cu. in. (295 cu.cm) of total capacity. This assembly is shipped with a scrub water gasket and requires a 4'' (102mm) diameter hole with an overall floor depth of 1'' (25mm) to install.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Color | Brass |
| TAA Compliant | Yes |
| Certifications | TAA |
| Warranty | 1-Year from Installation or 2-Years from Day of Sale |
Resources
Questions about this part
What type of floor can the 861QTCAB be installed in?
This assembly is rated for use in tile, wood, or carpet floor installations.
What are the installation requirements for the 861QTCAB?
Installation requires a 4'' (102mm) diameter hole and an overall floor depth of 1'' (25mm).
Does the 861QTCAB include the receptacle?
Yes, this assembly is complete with a prewired 15A quad receptacle.
How many knockouts are available for conduit entry?
The unit features three 1/2'' trade size knockouts: two located on the sides and one on the bottom.
Is this product TAA compliant?
Yes, the 861QTCAB is TAA compliant and carries cULus and RoHS certifications.
