6P6C Keystone Connector in Light Almond
Cat5e Keystone Connector in Light Almond with a vertical orientation for easy punchdown termination
The On-Q WP3425LA is a high-quality AnyPort insert designed for use within all AnyPort Wall Plates. This 6P6C keystone connector is specifically engineered for Cat5e cable types and features a vertical orientation to facilitate easy punchdown termination during installation. The jack housing is constructed from high-impact, flame-resistant plastic that meets UL 94V-0 standards. To ensure a secure wire termination, these connectors utilize rear retention caps and phosphor bronze alloy spring wire, which is plated with 50 micro-inch of gold over 100 micro-inches of nickel.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Cable Type | Cat5e |
| Color | Light Almond |
| Orientation | Vertical |
Resources
Questions about this part
What type of cable is the WP3425LA compatible with?
This keystone connector is designed specifically for use with Cat5e cable types.
Will this work in my AnyPort Wall Plate?
Yes, this AnyPort insert is intended for use in all AnyPort Wall Plates.
What is the termination orientation for this connector?
The WP3425LA features a vertical design to make punchdown termination easier during installation.
What are the material specifications for the internal wiring?
The spring wire is made of a phosphor bronze alloy plated with 50 micro-inch of gold over 100 micro-inches of nickel.
