30ft (9.1m) Cat6 Non-Booted Unshielded UTP Ethernet Network Patch Cable - Pink
30ft pink Cat6 Unshielded UTP Ethernet patch cable with stranded copper conductors and RJ-45 male connectors
The C2G CG04268 is a 30ft (9.1m) Cat6 Unshielded UTP Ethernet network patch cable designed for bandwidth-intensive applications including voice, data, and video distribution. This cable is constructed with high quality stranded copper conductors and features a 0.24 in (6 mm) cable diameter. It is engineered to meet all Cat6 TIA/EIA standards, which helps to drastically reduce impedance and structural return loss (SRL) while minimizing Near-End Crosstalk (NEXT) levels. Each individual pair is bonded together to maintain consistent twist-spacing throughout the line up to the termination point. This pink cable utilizes a T568B wiring scheme and features two RJ-45 male connectors in a non-booted configuration. The jacket is made of PVC and is rated for standard, non-rated environments with a temperature rating of up to 75°C. This specific SKU is part of a larger series of Cat6 Non-Booted Patch Cables available in various lengths and colors to facilitate network color-coding.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Cable Diameter | 0.24 in (6 mm) |
| Cable Length | 30 ft (9.1 m) |
| Shield Type | UTP |
| Shipping Weight | 0.82 lbs (0.4 kg) |
| Wire Gauge | 24 |
| Wiring Scheme | T568B |
| Cable Shielding | Unshielded (UTP) |
| Cable Type | Cat6 |
All other specifications 13
| Category Performance Application | Cat6 |
| Color | Pink |
| Conductor Material | Copper |
| Conductor Stranding | Stranded |
| Connector 1 | (1) RJ-45 Male(1) RJ-45 Male |
| Connector 2 | (1) RJ-45 Male(1) RJ-45 Male |
| Connector Type | Non-booted |
| Jacket Rating | Standard / Non-Rated |
| Product Type | Cable |
| TAA Compliant | No |
| UPC | 757120042686 |
| Certifications | CENDAA 889NDAA 889Prop 65Prop 65REACHREACHRoHSRoHSTSCATSCA |
| Jacket Material | PVC |
Questions about this part
What is the wiring standard for the C2G CG04268?
This 30ft Cat6 patch cable uses the T568B wiring scheme for its RJ-45 male connectors.
Is this cable suitable for high-bandwidth video or data distribution?
Yes, this Cat6 cable is designed for Gigabit computer networks requiring high bandwidth for voice, data, or video distribution applications.
What is the cable diameter and jacket material of the CG04268?
The cable has a 0.24 in (6 mm) diameter and is constructed with a PVC jacket material.
Does this cable include boots on the connectors?
No, the CG04268 is a non-booted connector type cable.
What is the maximum operating temperature for this cable?
This cable has a temperature rating of 75°C.
