1-Port Cat5E Surface Mount Box - White
White 1-port Cat5E surface mount box for networking in confined spaces, featuring 110/KRONE IDC termination and a snap-on cover
The C2G CG03835 is a single-port Cat5E surface mount box designed specifically for networking installations in confined spaces. This white junction box supports either side or base entry for incoming cables to accommodate various mounting requirements. It features a 110/KRONE Universal IDC connector, which facilitates vertical termination for 22-26 AWG UTP solid wire. The unit is compatible with T568A wiring standards and meets Category 5 enhanced requirements. For efficient installation and maintenance, the box includes a snap-on cover for quick access, a cable tie for strain relief, and a write-on label with a holder to ensure easy station designation. The internal contacts are phosphor bronze plated with 50 inch hard gold to maintain connection integrity.
No documents are published for this part. Ask us for the paperwork and we will get it from the manufacturer.Key features
Specifications
| Shipping Weight | 0.09 lbs (0 kg) |
| Color | White |
| Connector 1 | (1) RJ-45 Female(1) RJ-45 Female |
| Number of Ports | 1 |
| Product Type | Surface Mount Box |
| TAA Compliant | No |
| UPC | 757120038351 |
| Certifications | NDAA 889Prop 65REACHRoHSTSCA |
| Warranty | Lifetime |
Questions about this part
Will this box work with T568A wiring?
Yes, the CG03835 is compatible with T568A wiring and meets Category 5 enhanced requirements.
What kind of wire can be used with the IDC connector?
The 110/KRONE Universal IDC connector is designed for vertical termination of 22-26 AWG UTP solid wire.
How is the cable entered into the CG03835 box?
The box is designed to allow for either side or base entry of cables, making it suitable for confined spaces.
Does the CG03835 include everything needed for installation?
The box comes equipped with mounting screws, adhesive tape, a cable tie for strain relief, and a snap-on cover.
What certifications does this surface mount box hold?
The product is EIA/TIA 568A certified and complies with NDAA 889, RoHS, REACH, and TSCA standards.
