Height adjustment range optimized to enable sit-to-stand use of a fixed-height desk when paired with Chief’s K1-series dynamic monitor arms, the KBD-S2S-19T provides easy placement of the keyboard and mouse for better ergonomic support. S2S keyboard arm provides easy height adjustment range from 7" (178 mm) above to 5.5" (140 mm) below the work surface to meet the natural typing height of a user whether sitting or standing at the workspace. 19T keyboard tray provides ample room for most keyboards, and ergonomic positioning of mouse tray.

Keyboard Arm:

• Sit-to-Stand keyboard arm is ideal for standing at a fixed-height desk, in combination with Chief’s K1-series dynamic monitor arms
• Height adjusts without knobs or levers - simply move the keyboard tray to the desired position and release
• 12.5" (317 mm) total height adjustment range: +7″ (178 mm) above, -5.5″ below (140 mm) the worksurface
• No knob, lever, or ratchet handle required to set height - simply lift to desired position and release
• Soft-touch wheel adjusts tilt with each turn (+10°/-20°)
• Positive tilt lock-out feature can be field installed
• Counterbalance design offsets keyboard weight during height and tilt adjustment
• Slim profile provides maximum knee clearance, whether in use or retracted for storage
• Rear swivel rotates 360° for optimal keyboard tray positioning and easy stowage
• Closed-channel design provides maximum keyboard stability
• Rugged steel construction finished in a durable black textured powder coat
• 23" (584 mm) track included
• Exceeds ANSI / BIFMA X5.5 1998 industry standard
• All mounting hardware and instructions included

Keyboard Tray:

• 19.5″ wide x 11.5″ deep (495 x 292 mm), with 8.25″ (210 mm) diameter round mouse surface
• 1/4″ (6 mm) thin phenolic allows maximum knee clearance
• Tilt & swivel mouse surface with foam pad provides infinite adjustment
• Foam palm rest (removable) for maximum ergonomic comfort
• Sliding mouse catcher with cord manager
• Mouse platform mounts on right or left

Specifications:
• Length: 17
• Height: 16
• Width: 30
• Warranty: Not Applicable
• Color: Black_Grey with Black Accents
